ART introduces XL231 dual 31-band graphic equalizer

The XL231 has been designed and engineered to exceed extremely high standards for design specification and audio performance. This flagship EQ is precise and flexible, with the quality components and innovative features necessary for top-level professional audio performance.

The XL231 filter sets utilize precision 1% resistors and 2% capacitors. The active gain elements used throughout are all ultra low noise, and low distortion, resulting in a total dynamic range specification of >=123dB, thereby making these equalizers perfect for all applications where precision processing and silent operation are of the utmost priority. Rugged construction and solid audio performance make these equalizers well suited for touring live-sound systems as well as for fixed installations where their detachable Euroblock interface connectors come in handy.

The XL231 features ART’s exclusive two knob Low and High Trim filter set. Each control applies a gentle upward or downward slope to the overall frequency response. The Low and High Trim controls affect frequencies below and above 1KHz, respectively. These controls are extremely useful for making subtle adjustments to the overall sound after the room has been “rung” out for feedback nodes.

You can easily fine tune the lows and highs as they change over time resulting from changes in audience size, and/or atmospheric conditions such as temperature and humidity which will affect high frequency absorption, (technically referred to as adiabatic absorption compensation).

The XL231 additionally features a narrowband Enhanced Cut Mode with –18dB cut capability for notching particularly difficult feedback nodes without adversely affecting adjacent frequencies.

Each individual filter band in an XL231 equalizer has a precision center frequency and constant Q response which is narrow enough to prevent unnecessary interaction between filters, yet wide enough to create the exact natural sounding audio response that the user requires. These filter sets utilize an interleaved summing topology to further reduce adjacent band interaction, assuring rapid and accurate room tuning.

The XL213 utilizes 45mm, metal shaft, oil-damped precision slide potentiometers for extremely accurate and smooth operation, and they feature grounded centertapped resistive elements providing a true low noise, flat zero setting.

XL231 equalizers provide automatic relay bypass of audio, an essential function if power to the unit is lost. They also utilize a variable input level control, 10 segment LED level indicators with Peak Hold and clip indicator, Toroidal Power Transformer with selectable AC line voltage. Additional features include RFI filtering, selectable Scale Switching – higher slider resolution ±6(-9*)dB – or normal slider resolution ±12(-18*)dB, active balanced input/output XLR and Euroblock connectors.

The XL231 contains high voltage (40V) internal circuitry thereby allowing it to effortlessly drive long lines with signal to spare, while also providing wider dynamic range for your system overall.

* While In Enhanced Cut Mode

The XL231 will be available at music specialty stores Worldwide October 2005. MSRP on XL231 is $449.
