New Storn Maga Analog Synthesizer

Storn MAGA, “first” commercial Analog Synthesizer created by Storn System, MAGA‘s name itself taken from the name of fourth month in the Sundanese calendar, since the ideas and concepts about MAGA was born in April 2013.

Analog Modular Synthesizer

The MAGA’s concept inspiration designed when Evans Storn experimenting with functions of synthesizer from another brand, watch demonstrations on the net which he never tried before and after that he pouring all of the experiences along with his personal DIY (Do It Yourself) analog synthesizer. From all of that circumstances and based upon thought on the advantages and disadvantages of analog synthesizer, finally the idea of Storn MAGA formed.

Storn MAGA itself is Analog Modular Synthesizer, which is there are analog and digital technology processes, or called hybrid, the outcome and process in Storn MAGA is pure analog, with features given include things like Voltage Controlled Oscillator, Voltage Controlled Filter, Voltage Controlled Amplifier, Low Frequency Oscillator, Attack Decay Envelope, ADSR  Envelope and Noise.

Digital functions of MAGA is simply to process MIDI control system and modulation patch routing storage (saving routing analog path, as a substitute of input / output cables routing path that found in a normal modular analog synthesizer), which could keep about 40 presets.

Features

  • VCO, VCA, VCF, LFO, AD Envelope, ADSR Envelope, Noise
  • VCO with multiple independent output
  • VCO input from CV IN
  • Processing external input from instrument such as guitar, bass, drum, vocal etc.
  • MIDI IN and MIDI OUT
  • Patch Matrix with save and edit system
  • Complex mixer routing (input/output path)
  • Portable Case

Specification

  • 1 VCO (SINE, TRI, SAW, SAW SHAPE, SUB)
  • 1 VCF (LPF/BPF)
  • 1 VCA WITH Modulation DRIVE
  • 1 NOISE (WHITE / PINK NOISE)
  • 1 LFO (TRI / SQUARE)
  • 1 ADSR ENV
  • 1 AD ENV (CHAOS LFO / AD envelope can receive input trigger via LFO output)
  • 1 SAW SQUARE LFO (CHAOS LFO)
  • 1 EXTERNAL AUDIO
  • PRESET MODULATION MATRIX (40 preset)
  • HEADPHONE OUT
  • MIDI IN/OUT
  • MIDI OUT (CONTROLLER)
  • CV GATE IN
  • CV GATE OUT
  • AC INPUT SUPPLY

Storn Maga will be produced no more than 50 pieces, so far there’s about 10 pre-orders already. Will be ready at the beginning of February for the first 10 pieces. The price will be US$1,500 (exclude VAT, Shipping and Handling).
